IP65 Terminal Box Waterproof Outdoor Manufacturer & Exporter

Terminal Junction boxes IP rated — Connections Made Easy.
Never before !!

Readymade Terminal Boxes

We Idis India are manufacturer and exporter of IP65 Terminal Box. Since we manufacture enclosures in house, we have always stock of the boxes and we can ship the products in tight schedules. We have standard range of ready to use terminal junction boxes with terminals and glands fitted in it.s. This Standard range is ready to use with your retail and bulk orders and mostly in stock. IP67 and IK08 test reports available on request. Range starts from 4 Sqmm 4 terminals. Customized orders are possible for bulk orders.

IP67 Waterproof

Real IP67 Waterproof Enclosures with EPDM sponge gasket. Get test reports of all our products from NABL Approved laboratory only. Ensure IP67 ratings are for Enclosures only not for Terminal boxes.

IK08 Impact Resistance

IK08 Impact resistance for ABS and IK09 for fully Polycarbonate Enclosures. Test reports from NABL Approved laboratory. 3mm thick abs or Polycarbonate body withstands heavy loads.

Customization Available

If you have large voluems, We can supply Terminal Junction bozes as per your requirements, We need qty of cable glands, qty of terminals and size of box for bulk volumes.

Global Supply

We supply all our products within almost all state of India including, Mizoram, Manipur, J&K etc via transport, courier, india post etc. We Export to different countries via Sea and Air mode in LCL and FCL.

Factory Supply

We dont deal with Dealers and distributors, Most of all our products are shipped from our factory only. This makes it cost effective and ready available stocks. Retail orders are shipped from our online website.

Reasonable Price

We are customers choice for reasonable price with cost to service reliability. Due to our transparent pricing structure based on volumes, it has created great impact on our trust.

IP65 Terminal box Range

The range starts with 4 Terminals of 4 Sqmm and two PG 13.5 Cable Glands. These terminal junction box are designed for the general purpose applications up to 6 sqmm flexible cables. We recommend to use 4sqmm terminal upto 2.5MM cable and 10 Sqmm terminal up to 6Sqmm cables. All our terminal boxes are made with vergin ABS material with thickness of 2.5mm to 3mm. We use Nylon cable glands for cable inlet and outlets. All terminal junction boxes includes wall mounting accessories.

IP65 Terminal box 4 Sqmm 4 Terminals by Idis India

4 Terminal – 4 SQMM IP65 Terminal box

Enclosure of 100 x 100 x 80 mm with 4 Terminals of 4 Sqmm.
Din rail fitted with two PG13.5 Nylon cable glands.
Two end stoppers with Endplates fitted on each terminals.
Size in Inch : 4 x 4 x 3.5 Inch

Packing : 80 Nos per Carton

SKU 10319

IP65 Terminal Box 10 Sqmm 4 Terminals by Idis India

4 Terminal – 10 SQMM IP65 Terminal box

Enclosure of 100 x 100 x 80 mm with 4 Terminals of 10 Sqmm.
Din rail fitted with two PG13.5 Nylon cable glands.
Two end stoppers with Endplates fitted on each terminals.
Size in Inch : 4 x 4 x 3.5 Inch

Packing : 80 Nos per Carton

SKU 10318

Terminal JB 4 Sqmm 6 Terminals by Idis India

6 Terminal – 4 SQMM IP65 Terminal box

Enclosure of 100 x 100 x 80 mm with 6 Terminals of 4 Sqmm. Din rail fitted with two PG13.5 Nylon cable glands.
Two end stoppers with Endplates fitted on each terminals.
Size in Inch : 4 x 4 x 3.5 Inch

Packing : 80 Nos per Carton

SKU 10320

IP65 Terminal box 4 Sqmm 8 Terminals by Idis India

8 Terminal – 4 SQMM IP65 Terminal box

Enclosure of 100 x 100 x 80 mm with 8 Terminals of 4 Sqmm.
Din rail fitted with two PG13.5 Nylon cable glands.
Two end stoppers with Endplates fitted on each terminals.
Size in Inch : 4 x 4 x 3.5 Inch

Packing : 80 Nos per Carton

SKU 10322

IP65 Terminal box 10 Sqmm 8 Terminals by Idis India

8 Terminal – 10 SQMM IP65 Terminal box

Enclosure of 150 x 100 x 70 mm with 16 Terminals of 4 Sqmm.
Din rail fitted with Four PG13.5 Nylon cable glands.
Two end stoppers with Endplates fitted on each terminals.
Size in Inch : 6 x 4 x 3 Inch

Packing : 75 Nos per Carton

SKU 10321

IP65 Terminal box 4 Sqmm 12 Terminals by Idis India

12 Terminal – 4 SQMM IP65 Terminal box

Enclosure of 150 x 100 x 70 mm with 12 Terminals of 4 Sqmm.
Din rail fitted with Four PG13.5 Nylon cable glands.
Two end stoppers with Endplates fitted on each terminals.
Size in Inch : 6 x 4 x 3 Inch

Packing : 75 Nos per Carton

SKU 10315

IP65 Terminal box 10 Sqmm 12 Terminals by Idis India

12 Terminal – 10 SQMM IP65 Terminal box

Enclosure of 140 x 190 x 100 mm with 12 Terminals of 10 Sqmm.
Din rail fitted with Six PG13.5 Nylon cable glands.
Two end stoppers with Endplates fitted on each terminals.
Size in Inch : 5.5 x 7.5 x 4 Inch

Packing : 40 Nos per Carton

SKU 10314

Terminal JB 4 Sqmm 16 Terminals by Idis India

16 Terminal – 4 SQMM IP65 Terminal box

SKU 10316

IP65 Terminal box 4 Sqmm 20 Terminals by Idis India

20 Terminal – 4 SQMM IP65 Terminal box

Enclosure of 140 x 190 x 100 mm with 20 Terminals of 4 Sqmm.
Din rail fitted with Six PG13.5 Nylon cable glands.
Two end stoppers with Endplates fitted on each terminals.
Size in Inch : 5.5 x 7.5 x 4 Inch

Packing : 40 Nos per Carton

SKU 10317

Frequently Asked Questions

What is the IP rating of your terminal junction boxes?

Our standard terminal boxes are IP65 rated. IP67 rated enclosures are also available. Test reports from NABL approved laboratory available on request. These are enclosure ratings, IP67 voids in terminal boxes. We recommend to position cable glands at bottom side only for outdoor rainy applications.

What sizes of terminal junction boxes are available?

Our range starts from 4 Terminals of 4 Sqmm up to 20 Terminals of 10 Sqmm in various enclosure sizes from 100x100x80mm to 140x190x100mm.

What cable sizes are compatible with your terminal boxes?

We recommend 4 Sqmm terminals for cables up to 2.5mm and 10 Sqmm terminals for cables up to 6 Sqmm flexible cables. Customized terminal boxes can be made for volumes only.

Are customized terminal boxes available?

Yes, customization is available for bulk orders only. we need all details like – number of terminals, cable glands, and box size etc along with any specific requirements with detailed drawings.

What material is used in enclosures?

All terminal boxes are made from virgin ABS material with 2.5mm to 3mm thickness. Nylon cable glands are used for cable inlets and outlets.

Do you supply pan-India including remote locations?

Yes, we ship across all states including Mizoram, Manipur, J&K via transport, courier, and India Post.

Do you export terminal junction boxes?

Yes, we export globally via Sea and Air in LCL and FCL modes.

Do you sell through dealers or distributors?

No, we supply directly from our factory. Retail orders are shipped via our online website. This is hard decision but helps for after sales services and maintain customer satisfaction ratios.

What is the impact resistance rating?

IK08 for ABS enclosures and IK09 for fully Polycarbonate enclosures. Test reports from NABL approved laboratory available.

Are wall mounting accessories included?

Yes, all terminal junction boxes include wall mounting accessories as standard.
